Design of assembly fixture for car door outer handle component

Wu Wenping , Wen Genbao 2
1
(1. Panasonic Appliances Washing Machine (Hangzhou) Co. LTD., Hangzhou 310018, Zhejiang, China;
2. China Aviation Industry Aerospace Lifesaving Equipment Co. LTD., Xiangyang 441002, Hubei, China)
Abstract: The assembly of the car door outer handle assembly is completed by inserting the positioning
stop pin into the shifting block, swing block, torsional spring, and the holes at the front and middle ends of
the outer handle. In the initial stage of assembly, two operators are used for manual operation. However,
due to the large production volume, traditional initial assembly methods are difficult to meet the demand.
To this end, hydraulic assembly fixtures were introduced on the basis of manual operation. The fixture adopts
a positioning plate for full shape positioning of the outer handle, and the swing block and the fixture’s
positioning block in the component also need to be moved and positioned to ensure that the component
has a unique positioning position in the fixture. Subsequently, the operator controlled the hydraulic retraction
mechanism of the distribution valve by stepping on the microcontroller, completed the insertion of the
positioning stop pin, and achieved the assembly of the outer handle component. Due to the use of assembly
fixtures, the assembly process of the outer handle component not only saves one person's labor and doubles
the assembly efficiency, but also significantly improves the assembly quality. If the loading, unloading, and
positioning of components can be automated, then the entire assembly process will be fully automated.
Key words: outer handle component; manual operation; assembly fixtures; full form positioning; retraction
mechanism
（R-03）

住友橡胶高层变动，开启新征程
Sumitomo Rubber's top management changes to start a new journey

近日，全球知名轮胎品牌邓禄普总部住友橡胶工业株式会社宣布高层人事变动。井川潔于 2025 年 3 月 27 日
正式上任，接替増田智彦就任住友橡胶（中国）有限公司董事长兼总经理、住友橡胶（常熟）有限公司董事长、
住友橡胶（湖南）有限公司董事长，全面负责住友橡胶在中国区的业务发展。
此次变动是住友橡胶集团全球战略调整的重要步伐，旨在推动集团公司的业务转型和市场拓展。同时，也凸
显了住友橡胶集团对中国市场的重视程度。
新任董事长井川潔，自加入住友橡胶以来，先后在人事、体育事业等多个部门任职，并且多次外派印度尼西亚、
澳大利亚等国家和地区，拥有丰富的海外业务经验，对中国乃至全球汽车行业的发展趋势有着深刻洞察和独到见
解。
当前，在绿色化和智能化的大趋势下，中国轮胎行业正迎来新的发展机遇和挑战。井川潔董事长表示，将带
领住友橡胶中国 “ 内外兼修 ” 来迎接不断变化的市场环境。对内完善组织体质，不断加大高端技术投入。对外将
紧跟集团总部战略，借助总部强大的资源优势，加速整合渠道资源。同时会将毕生所积累的工作经验运用到中国
市场，为市场注入新的活力，带领邓禄普品牌迈向新高度，共创住友橡胶中国区的新辉煌！
