Page 66 - 《橡塑技术与装备》2024年1期

橡塑技术与装备 CHINA RUBBER/PLASTICS TECHNOLOGY AND EQUIPMENT

1.15 导开装置
导开装置 ：①双电机控制，“ 零张力 ” 导开，最
大限度减小物料的拉伸变形 ；②匀速导开 ；倒卷功能 ；
③可选台车纠偏功能，如图 17。

图 15 自动上圈系统

图 17 导开装置

2 结语
综上所述，江苏中进机械有限公司通过近两年时
间，厚积薄发，以一次法的核心理念及智能化技术从
根本上提升两段成型机，打破了一次法和两段之间的
鸿沟，实现了 “ 两段工艺，一次法效率 ” 的目的。将
两段成型机真正做到了全自动、无人操作的国际领先
水平。
图 16 自动上圈位置示意图

Development of a two-stage one-step building machine for
semi-steel radial tires

Li Zhijun
(Jiangsu Zhongjin Machinery Co. LTD., Changzhou 213300, Jiangsu, China)
Abstract: The two-step and one-step in the forming of semi-steel tires have always been parallel. In recent
years, the one-step equipment has developed rapidly, which has led to the gradual marginalization of two-
step technology. Even the AT and MT light truck series tires that two-step is good at do not have corresponding
equipment to use. This article aims to provide a highly intelligent and efficient two-stage building method and
building equipment.
Key words: two-stage; one-step; intelligence; green; turn up and turn down
(R-03)

1
·20· 第 50 卷 第 期
